GP-3150TIN Thermal Barcode Printer
- Classic model
- Automatic label detection function
- Multiple interfaces, USB+Serial+Ethernet
- Support thermal paper rolls and self-adhesive paper, support media width 25mm~82mm
- Automatic paper calibration function, automatic temperature control, durability
- Support 2D barcode printing to meet different application requirements
- Printing speed at 6 inch/s, supports thermal paper roll
- Support paper width 25-82mm
- Easy operation
Call for More Details
Description
| Print method | Direct thermal |
|---|---|
| Resolution | 203DPI |
| Print speed | 2~6 inch/s |
| Print width | 76 mm |
| Print head temperature detect | Thermal sensitive resistance |
| Print head position detect | Mircoswitch |
| Paper detect | Photoelectric sensor |
| Memory | DRAM:8M FLASH:4M |
| Interface | USB+Serial+Ethernet |
| Graphics | Monochrome PCX, BMP and other graphics files can be downloaded to FLASH/DRAM |
| Barcode | CODE128, EAN128, ITF, CODE39, CODE93, EAN13，EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR，POSTNET, UPC-A, UPC-A+2, UPC-A+5, UPC-E, UPC-E+2，UPC-E+5，CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14/QRCODE |
| Character set | Common single-byte fonts: FONT 0 to FONT 8 |
| Character enlargement / Rotation | 1 ~10 times enlargement in portrait and landscape orientation; 0°, 90°, 180°, 270°degree rotation |
| Media type | Thermal roll paper, self-adhesive paper, etc. |
| Media width (with backing paper) | 25-82mm |
| Media roll core size | 25.4mm |
| Media roll inner diameter | 25mm (min.) |
| Media roll outer diameter | 97mm (max) |
| Paper output method | Front paper output / peel off / tear-off |
| Input | input: DC24V 2.5A |
| Working environment | 5~40℃, 20~90%RH |
| Storage environment | -25~55℃, 20%~93%RH |
| Printer weight | 1.62kg |
| Printer dimension | 231×156×145mm |
| Packing dimension | 260×210×230mm |
| Print head (reliability) | 30km |
| Printer certificate | CE, FCC, CCC, RoHS, SRRC |
